EDIFACT.NET

EdiFabric C# .NET Examples for EDIFACT D96A, EANCOM D03B, EDIGAS 4.0, and IATA PNRGOV

View the Project on GitHub EdiFabric/EDIFACT.NET

EdiFabric C# .NET Examples for EDIFACT D96A, EANCOM D03B, IATA PADIS, and eDIGAS

1. Overview

EdiFabric is a software development kit for .NET Framework and .NET Core, which makes it straightforward to parse, generate, validate, acknowledge, split, customize, or in other words, to programmatically manipulate EDI files. It is written in C# and is distributed as a DLL file and a NuGet package.

It currently supports all message types for the X12, EDIFACT, HL7, and NCPDP EDI standards, the German automotive standard VDA, as well as custom formatted flat files (delimited, positional, or a mixture of both).

NOTE: EdiFabric does not provide any communication components (AS2 or SFTP, for example), has no dashboard or UI, and is not a full end-to-end EDI solution. The best option to get the gist of what EdiFabric is, and can do, is to play around with the trial and examples.

The examples are organized into different projects in two logical categories: by product feature and by message type.

var ediStream = File.OpenRead(Directory.GetCurrentDirectory() + @"\..\..\..\Files\Edifact\PurchaseOrder.txt");

List<IEdiItem> ediItems;
using (var ediReader = new EdifactReader(ediStream, "EdiFabric.Templates.Edifact"))
    ediItems = ediReader.ReadToEnd().ToList();

var transactions = ediItems.OfType<TSORDERS>();

2. Requirements

3. Serial Key and EdiFabric trial DLLs

All projects reference EdiFabric EDI Tools as NuGet packages from nuget.org. If you wish to install EdiFabric EDI Tools as DLLs, download the trial DLLs from here.

4. Setup

Rebuild the solution with Package Restore enabled. If there are any build errors, manually install the missing packages from here.

5. Getting started

To get started, set project EdiFabric.Examples.EDIFACT.Demo as the startup project, open Program.cs and follow the instructions there. This project allows you to quickly translate your own EDI files.

6. Examples by feature

Explore the different features of EdiFabric, such as translating from EDI file (ReadEDI), generating EDI file (WriteEDI), validating EDI transactions (ValidateEDI), import/export from/to JSON , XML, CSV, create/save/query database (DB), generate CONTRL acknowledgments (AcknowledgeEDI) and how to map to/from an EDI template using Automapper and XSLT (MapEDI).

7. Examples by message type

Explore how to translate from and generate several of the most popular EDIFACT transactions. The following examples are included; please let us know if you need a different one:

EANCOM INVOIC Syntax 3
SMDG BAPLIE
US Customs CUSCAR
US Customs PAXLST
IATA PNRGOV
EDIGAS NOMINT
EDIFACT UN DESADV
EDIFACT UN IFTMIN
EDIFACT UN IFTSTA
EDIFACT UN INVOIC
EDIFACT UN ORDERS
EDIFACT UN ORDRSP
EDIFACT UN PRICAT

If you need to test with a message type in a different version, install the templates for that version from EdiNation.

8. EDI Validation

All templates in EdiFabric.Templates.Edifact and EdiFabric.Templates.Padis can be used for validation.

9. EDI Templates

EdiFabric supports all EDIFACT/EANCOM/IATA versions and message types. We have an extensive library of EDI templates, however, if you can’t find a particular transaction, please let us know.
The following templates are available out-of-the-box:

EDIFACT

EANCOM

IATA PADIS

EDIGAS

For an interactive view of all templates go to EdiNation (no registration is required):

EdiNation

10. Trial use

The trial serial key is valid for 14 days, and using the product with a trial license is subject to EdiFabric’s license terms available at https://www.edifabric.com/files/eula.pdf. Upon expiry, the product will begin throwing exceptions. To continue using the trial and the examples, you’ll need to request a trial extension.

11. Warranty

The source code in these example projects is strictly for demonstrational purposes and is provided “AS IS” without warranty of any kind, whether expressed or implied, including but not limited to the implied warranties of merchantability and/or fitness for a particular purpose.

12. Additional information

Install EdiFabric

Trial and Examples

EdiFabric DB

EdiFabric Tutorial

Knowledge Base

Support

Last updated on June 20, 2023
